Hubble AM-10 Lithium Battery 10kWh 51.2V – Wall Mountable

Description

Hubble AM-10 Lithium Battery – 10kWh 51.2V

The Hubble AM-10 Lithium Battery (10kWh 51.2V) is one of the largest and most powerful models in the popular Hubble AM Series. Built with superior LiFePO4 prismatic cells, the AM-10 delivers massive 10kWh storage capacity, advanced monitoring, and 15+ years of design life, making it the ideal solution for homes, businesses, and industrial backup systems.

As a direct upgrade to the Hubble AM-5, this unit doubles the storage capacity while maintaining reliability, efficiency, and safety. With unlimited cycles under Hubble’s 10-year warranty, the AM-10 is engineered for long-term performance and peace of mind.

---

Key Features of the Hubble AM-10

• 10kWh energy capacity | 51.2V 200Ah

• Wall mount or rack installation for versatile setups

• 0.75C high-performance LiFePO4 battery

• Advanced BMS with current limiting for safety

• Cloudlink ready – real-time performance monitoring

• Built-in CAN Bus for seamless inverter communication

• Heavy-duty side handles for easy installation

• Excellent high-temperature performance

• Over-charge, over-discharge & over-temperature protection

• Compatible with most inverters & chargers

• Unlimited cycles covered by Hubble’s 10-year warranty

---

Technical Specifications

• Model: Hubble AM-10

• Rated Capacity (5HR): 200Ah

• Nominal Voltage: 51.2V

• Energy Storage: 10kWh

• Equalized Charge Voltage: 55.2V

• Max. Continuous Charging Current: 150A

• Max. Continuous Discharging Current: 150A

• C Rating: 0.75C

• Weight: ~89kg

• Dimensions (W x D x H): 673mm x 618mm x 193mm

• Connections: CAN-bus, Battery Link Ports

• Parallel Capability: Up to 8 packs with full communications

• Monitoring: Optional Cloudlink integration

• Cells: Prismatic LiFePO4

• Cycle Life: Unlimited cycles within warranty (10 years, Ts & Cs apply)

• Design Life: ±15 years

• Certifications: CE, IEC, UN38.3

• Casing: White bake lacquer steel case

• Operating Temperature:

  • Charging: -10°C to +50°C

  • Humidity: 15% – 75%

  • Storage: 10°C to +50°C

• Protection: Electronic Circuit Breaker, BMS Voltage Protection, Current Limiting

---

Why Choose the Hubble AM-10 Lithium Battery?

• Massive 10kWh storage – double the size of the AM-5

• Future-proof backup power for homes, businesses, and solar systems

• Advanced BMS & CAN Bus communication ensures smooth operation

• Cloudlink ready for intelligent monitoring and system control

• Durable & long-lasting – unlimited cycles under warranty

---

Hubble AM-10 User Resources

• Axpert Inverter & Hubble Battery Set-up Guide

• Deye Inverter & Hubble Battery Set-up Guide

• Sunsynk Inverter & Hubble Battery Set-up Guide

• Kodak Inverter & Hubble Battery Set-up Guide

• Luxpower Inverter & Hubble Battery Set-up Guide

• Hubble AM-2 Lithium Battery Brochure

---

Order the Hubble AM-10 Today

Upgrade to the Hubble AM-10 Lithium Battery (10kWh 51.2V) – a high-capacity, wall-mountable energy solution built for load shedding, off-grid systems, and business backup power. With Cloudlink monitoring, CAN Bus integration, and unlimited cycles, the AM-10 sets the standard for reliable energy storage.
